| Model | RS-500-ACAB-M3 |
| Type | lntel ATX 12V V2.3 |
| Dimension (W x L x H) |
150 x 140 x 86mm
5.9 x 5.5 x 3.4 inch
|
| Input Voltage | 180~264Vac |
| Input Current | 5A@230Vac |
| Input Frequency Range | 60~50Hz |
| PFC | Active PFC |
| Power Good Signal | 100 ~ 500 ms |
| Hold Up Time | >14ms |
| Efficiency | >85%@ Typical Load |
| MTBF | >100,000 Hours |
| Protection | OVP / OCP /OPP / SCP |
| Output Capacity | 500W |
| Operation Temperature | 0~40°C |
| Regulatory | CB / CE / CCC |
| Fan | 120mm Fan |
| Connector |
MB 20+4 Pin x 1 CPU12V 4+4 Pin x 1 PCI-e 6+2 Pin x 2 SATA x 6 4Pin Peripheral x 3 4Pin Floppy x 1 |
