CPU Socket Type |
AM1 |
|
CPU Type |
Athlon / Sempron |
|
|
|
|
Number of Memory Slots |
2×240pin |
|
Memory Standard |
DDR3 1600 non-ECC, Un-buffered |
|
Maximum Memory Supported |
16GB |
|
Channel Supported |
Single-channel |
|
|
|
|
PCI Express 2.0 x16 |
1 x PCI Express 2.0 x16 |
|
Mini Card Slots |
1 x Mini PCI Express x1 slot(s) |
|
|
Mini PCI Express X1 slot(s) doesn't support Mini SATA |
|
|
|
|
SATA 6Gb/s |
2 x SATA 6Gb/s |
|
|
|
|
Audio Chipset |
Realtek ALC662 |
|
Audio Channels |
6 Channels |
|
|
|
|
LAN Chipset |
Realtek 8111G |
|
Max LAN Speed |
10/100/1000Mbps |
|
|
|
|
PS/2 |
1 x PS/2 keyboard/mouse port |
|
COM |
1 |
|
Video Ports |
1 x DVI-I port(s) (optional) |
|
|
1 x D-Sub (VGA) port(s) |
|
HDMI |
1 x HDMI |
|
RJ45 |
1 x RJ45 |
|
USB 3.0 |
2 x USB 3.0 |
|
USB 1.1/2.0 |
4 x USB 2.0 |
|
Audio Ports |
1 x Audio port |
|
|
(Line Out/Line In/Mic In) |
|
|
|
|
Onboard USB |
2 x USB 2.0 |
|
Other Connectors |
1 x 24-pin ATX Power Supply connector |
|
|
1 x 4-pin CPU_FAN connector with smart fan |
|
|
1 x 4-pin SYS_FAN connector |
|
|
1 x Clear_CMOS button |
|
|
1 x Front panel audio header |
|
|
1 x Onboard Buzzer |
|
|
1 x S/PDIF out header |
|
|
2 x SATA III 6Gb/s connector(s) |
|
|
1 x CLR_CMOS header |
|
|
1 x Parallel port header (LPT) |
|
|
1 x Chassis intrusion header |
|
|
1 x VGA header (optional) |
|
|
|
|
Form Factor |
Mini ITX |
|
Power Pin |
24 Pin |
