| CPU | º Supports New 4th & 4th gen Intel® Core™ family, |
| Pentium, Celeron series processors in LGA1150 socket | |
| º DMI 5.0GT/s | |
| º 3 Phase Thermal Design Power | |
| º VRD 12.5 | |
| º 100% Solid capacitor design | |
| º Supports Intel® Turbo Boost 2.0 Technology | |
| º Please refer to CPU support list for details | |
| CHIPSET | º Intel® H81 Express Chipset |
| GRAPHICS | º Supports DirectX® 11 .1 |
| MEMORY | º Dual-channel DDR3 Memory architecture |
| º Supports 1600 non-ECC, Un-buffered SDRAM Memory | |
| º 2 X 240-pin DDR3 DIMM socket | |
| º Support up to 16 GB* | |
| º Note:Please refer to the latest Memory | |
| support list for details | |
| EXPANSION SLOT | º 1 X PCI Express X16 Gen 2.0 slot(s) |
| º 1 X PCI Express X 1 Gen 2.0slot(s) | |
| Storage | º Support by Intel® H81 Express Chipset |
| • 2 X Serial ATAIII 6Gb/s | |
| • 2 X Serial ATAII 3Gb/s | |
| Audio | º 6-Channel HD audio CODEC |
| º Realtek ALC662 6-channel High Definition audio CODEC | |
| º Realtek ALC662 | |
| ?Realtek ALC662 6-channel High Definition audio CODEC | |
| ?Meets performance requirements for Microsoft WLP | |
| 3.08 Vista premium and mobile PCs | |
| ?Six channel DAC supports 16/20/24-bit PCM | |
| format for 5.1 channel audio solution | |
| ?Emulation of 26 sound environments to enhance | |
| gaming experience | |
| ?Voice Cancellation and Key Shifting in Karaoke mode | |
| ?Compatible with Direct Sound 3D™, A3D™, I3DL2 | |
| LAN | º Realtek 8111G Gigabit Fast Ethernet Controller |
| º Wake-On-LAN | |
| USB | º Support by H81 Express Chipset |
| • 2 X USB3.0 port(s) up to 5Gb/s | |
| Back Panel 2 port(s) | |
| • 8 X USB2.0 port(s) Up to 480 Mb/s | |
| Back Panel 4 port(s) | |
| Onboard 4 port(s) | |
| º ECS EZ Charger (Gray USB header) | |
| REAR PANEL I/O | º 1 X PS/2 combo connector |
| º 1 X Audio port (Line Out/Line In/Mic In) | |
| º 1 X RJ-45 port | |
| º 1 X D-Sub (VGA) port(s) | |
| º 1 X DVI port(s) (HDMI port(s), optional) | |
| º 1 X Coxal S/PDIF Out port (s) | |
| º 2 X USB3.0 port(s) | |
| º 4 X USB2.0 port(s) | |
| CONNECTORS & HEADERS | º 1 X 24-pin ATX Power Supply connector |
| º 1 X 4-pin 12V Power connector | |
| º 1 X 4-pin CPU_FAN connector | |
| º 1 X 3-pin SYS_FAN connector with smart fan | |
| º 1 X 3-pin PWR_FAN connector | |
| º 1 X Front panel audio header | |
| º 1 X Speaker header | |
| º 2 X USB 2.0 header | |
| • Support additional 4 USB ports | |
| º Support EZ charger (gray color) | |
| º 1 X S/PDIF out header | |
| º 2 X SATA III 6Gb/s connector(s) | |
| º 2 X SATA II 3Gb/s connector(s) | |
| º 1 X Serial port header (COM) | |
| º 1 X Parallel port header (LPT) | |
| SYSTEM BIOS | º AMI BIOS with 64 MB SPI Flash ROM |
| º Supports M.I.B III Utility | |
| º Supports ACPI 5.0 & DMI | |
| º F7 hot key for boot up devices option | |
| º Dual Display | |
| º Support ECS EZ BIOS | |
| º Multi-Language BIOS | |
| FORM FACTOR | º mATX Form Factor |
| º 230 x 170mm | |
| OS Support | º Windows 7 32-bit |
| º Windows 7 64-bit | |
| º Windows 8 64-bit | |
| Certifications | º CE/FCC Certification |
| º ErP/EuP Certification | |
| º WHQL Certification | |
| º WHCK Certification |
