Port

8 port

Speed

10/100Mbps

Media Interfaces

RJ45

Manageable

No

Switching Features

Inexpensive fast ethernet solution for SOHO/Home

Auto MDI/MDIX crossover for all ports

Store-and-forward switching scheme

Full/half-duplex for ethernet/fast ethernet speeds

IEEE 802.3x flow control

Plug-and-play installation

RoHS compliant

Power Supply

Power On (Standby) DC input : 0.3 watt, AC input : 0.5 watt

Max DC input : 1.6 watt, AC input : 2.5 watt

Others

1.6Gbps switching fabric

Standards

IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)

IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)

ANSI/IEEE 802.3 NWay auto-negotiation

IEEE 802.3x flow control

Protocol

CSMA / CD

Data Transfer Rates

Ethernet: 10 Mbps (half duplex) & 20 Mbps (full duplex)

Fast Ethernet: 100 Mbps (half duplex) & 200 Mbps (full duplex)

Topologi

Star

Transmission Method

Store-and-forward

MAC Address Table

1K entries per device

MAC Address Learning

Automatic update
