Conductor
Material : CCA(Copper content 22%[?]31%)
Diameter : 0.57 mm ± 0.01 mm
American : Wire Gauge 23AWG
Insulation
Material : HDPE
Min. Average Thickness 0.21 mm
Diameter 1.02 mm ± 0.06 mm
Color (4 Pairs) Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Separator
Material PE
Specification Translucent 4.5 × 0.4 mm
Rip Cord
Material Polyester
Specification 500D
Sheath
Material PVC
Min. Average Thickness 0.5 mm
Diameter 6.5 mm ± 0.3 mm
Electrical
Max. DC Resistance of a Single Conductor 11.5[?]/100 m
Min. Insulation Resistance 5000M[?][?]km
Max. DC Resistance Unbalance 2% (pair intra), 4% (pairs inter)
Dielectric Strength No breakdown with 1KV DC for 1 min
Transmission
Characteristic Impedance 100 ± 15[?]
Near End Cross Talk [?]39.30 dB/100 m@250 MHz
Max. Attenuation 34.8 dB/100 m@250 MHz
Return Loss [?]17.3 dB/100 m@250 MHz
Mechanical
Tensile Strength Sheath[?]13.5 MPa, insulation[?]16 MPa
Elongation at Break Sheath[?]150%, insulation[?]300%
